Garrett ACE 250 Owners Manual: A Comprehensive Guide

Welcome! This guide provides essential information for operating your Garrett ACE 250, a popular metal detector known for its ease of use and reliable performance.

The Garrett ACE 250 is a highly regarded metal detector, particularly well-suited for beginners yet capable enough for experienced enthusiasts. It’s designed for all-purpose treasure hunting, from coins and relics to jewelry and more; Garrett Metal Detectors, a leading name in the industry, has engineered this model for user-friendliness and dependable performance across diverse terrains.

This detector boasts pre-set search modes, simplifying operation, while still offering customization options for those seeking greater control. Its lightweight design ensures comfortable use during extended searching sessions. The ACE 250’s affordability makes it an excellent entry point into the exciting world of metal detecting, offering a balance of features and value. It’s a robust and reliable tool for uncovering hidden treasures!

Unboxing and Component Checklist

Upon opening your Garrett ACE 250 package, carefully verify all components are present. You should find the ACE 250 control housing, a 6.5” x 9” PROformance coil, and a coil mounting bolt and washer. The package also includes an adjustable S-rod stem section and an armrest.

Additionally, check for the instruction manual – this guide! – and a Garrett product registration card. Some bundles may include headphones, though these are often sold separately. Inspect each item for any shipping damage. If anything is missing or damaged, immediately contact the retailer or Garrett Metal Detectors customer support for assistance. Proper inventory ensures a smooth start to your treasure hunting adventures!

Understanding the ACE 250’s Key Features

The Garrett ACE 250 boasts several features designed for both beginners and experienced users. Its five search modes – All Metal, Jewelry, Coins, Relics, and Custom – cater to diverse detecting scenarios. The adjustable sensitivity and discrimination allow you to fine-tune the detector to minimize interference and target specific metals.

A digital target ID system, with numbers 0-99, helps identify potential finds. The pinpoint feature narrows down the exact location of buried objects. Lightweight construction and adjustable stem ensure comfortable use for extended periods. These features combine to make the ACE 250 a versatile and user-friendly metal detector.

Frequency and Technology

The Garrett ACE 250 operates at a single frequency of 6.5 kHz. This frequency provides a good balance between sensitivity to a wide range of metals and depth penetration. It utilizes Very Low Frequency (VLF) technology, a standard in recreational metal detecting, known for its ability to effectively detect ferrous and non-ferrous targets.

VLF technology sends a signal into the ground and analyzes the returning signal to identify metallic objects. The ACE 250’s simplicity in frequency allows for straightforward operation, making it ideal for beginners, while still delivering reliable performance across various terrains and target types.

Display Panel Overview

The ACE 250’s LCD display panel provides crucial information during your search. Key elements include the Target ID cursor, which indicates the likely composition of detected objects with numbers 0-99. A discrimination scale shows segments you can exclude from detection. The battery level indicator keeps you informed of power status.

Additionally, the display features a sensitivity level indicator, showing the detector’s responsiveness. You’ll also find icons representing the current search mode and a pinpoint mode indicator for precise target location. Understanding these elements is vital for effective treasure hunting with your ACE 250.

Control Knob Functions

The ACE 250 utilizes a single control knob for navigating its menu and adjusting settings. Rotating the knob clockwise increases settings like sensitivity and discrimination, while counter-clockwise decreases them. Pressing the knob selects the highlighted menu option on the LCD display.

This versatile control manages power on/off, search mode selection, ground balance adjustments, and access to advanced settings. Familiarizing yourself with its dual function – rotation for adjustment and pressing for selection – is key to mastering the ACE 250’s operation and customizing your detecting experience.

Assembly Instructions

Begin by attaching the coil to the control housing. Align the coil connector with the housing’s receptacle and firmly push until it clicks securely into place. Next, insert the lower stem into the control housing, ensuring a snug fit. Then, attach the armrest to the lower stem, adjusting its position for comfortable arm support.

Tighten all connecting screws and bolts, but avoid over-tightening. Finally, adjust the stem length to suit your height for optimal balance and comfortable swinging motion. Proper assembly ensures stable operation and maximizes detecting efficiency. Double-check all connections before each use.

Installing Batteries

The Garrett ACE 250 requires four AA batteries for operation. Locate the battery compartment on the control housing, typically on the underside. Gently slide open the battery compartment cover. Insert four AA batteries, ensuring correct polarity – positive (+) and negative (-) ends align with the markings inside the compartment.

Replace the battery compartment cover, ensuring it clicks securely closed. Use only fresh, high-quality AA batteries for optimal performance. Avoid mixing old and new batteries. Low batteries can cause inaccurate readings or erratic behavior. Regularly check battery levels for consistent detecting.

Attaching the Coil and Armrest

Begin by attaching the search coil to the shaft. Align the coil connector with the corresponding connector on the shaft and firmly push them together until they click into place. Ensure a secure connection to prevent signal interference. Next, install the armrest. Slide the armrest onto the shaft, positioning it comfortably for your arm support.

Tighten the armrest screw to secure it in place, but avoid over-tightening. Adjust the armrest position for optimal comfort during extended use. A properly fitted armrest reduces fatigue and enhances control. Double-check both connections before operation for a stable and reliable setup.

Basic Operation: Powering On and Off

To power on your Garrett ACE 250, simply press the power button located on the control panel. The detector will initiate a self-test, indicated by the display panel lighting up and a brief audible tone. Ensure the battery is sufficiently charged for optimal performance. To power off the detector, press and hold the power button for approximately two seconds.

The display will turn off, confirming the device is deactivated. Always power off the detector when not in use to conserve battery life. Familiarize yourself with the power button’s location and operation for quick and easy control during your detecting sessions.

Ground Balance Adjustment

Ground balancing is crucial for accurate detection, minimizing interference from minerals in the soil. The ACE 250 features automatic ground balance, simplifying this process for users. However, understanding its function enhances performance. Begin by slowly sweeping the coil low to the ground in an open area, away from metallic objects.

Observe the display; a stable reading indicates proper ground balance. If erratic signals persist, slightly adjust the sensitivity. While the ACE 250 largely automates this, recognizing optimal settings improves target identification and reduces false signals, leading to a more productive and enjoyable detecting experience.

Sensitivity and Discrimination Settings

Sensitivity controls the detector’s ability to detect small or distant targets; higher settings increase range but also susceptibility to interference. Start with a moderate setting and adjust based on ground conditions. Discrimination allows you to filter out unwanted metals, like iron, reducing digging time.

The ACE 250’s control knob manages both. Experiment with different discrimination levels to find a balance between rejecting trash and retaining valuable finds. Remember, higher discrimination can mask deeper, weaker signals from desirable targets. Careful adjustment of both settings is key to maximizing your detecting efficiency.

Target Identification and Audio Tones

The ACE 250 utilizes both visual Target ID numbers and varying audio tones to help identify detected objects. Lower conductive targets, like iron, produce low-tone signals, while higher conductive targets, such as silver, generate higher tones.

The LCD screen displays a Target ID number, offering a general indication of the object’s composition. However, ground conditions and target depth can influence these readings. Learning to correlate the audio tones with the Target ID numbers is crucial for accurate identification and successful treasure hunting. Practice and experience will refine your interpretation skills.

Understanding the Target ID Numbers

The Garrett ACE 250’s Target ID system ranges from 0 to 99, providing a numerical representation of the detected object’s conductivity. Lower numbers (0-20) generally indicate iron or junk metal, while higher numbers (80-99) suggest potentially valuable targets like silver or copper.

However, these numbers are estimates and can be affected by soil mineralization, target size, and depth. A Target ID of 50 doesn’t definitively mean a coin; it’s a guide. Experienced users learn to interpret these numbers in conjunction with audio signals and digging experience to improve accuracy and minimize digging unnecessary holes.

Interpreting Audio Signals

The Garrett ACE 250 utilizes audio tones to help identify potential targets. A solid, consistent tone generally indicates a good, strong signal from a conductive object. Weak or erratic signals might suggest a deep, small, or heavily oxidized target.

Pay close attention to the tone’s quality; iron often produces a choppy, low-pitched sound. Different search modes emphasize specific tones for different target types. Learning to differentiate these subtle audio cues, combined with the Target ID numbers, significantly enhances your ability to locate valuable finds and avoid digging up unwanted trash. Practice is key!

Search Modes Explained

The Garrett ACE 250 offers several pre-set search modes designed for specific detecting scenarios. All Metal Mode detects all metallic objects, providing maximum depth but requiring more discrimination skill. Jewelry Mode optimizes detection for gold, silver, and platinum jewelry, filtering out most iron.

Custom Mode allows you to tailor discrimination patterns to your specific hunting environment. Each mode adjusts the detector’s sensitivity and discrimination settings automatically, simplifying operation for beginners. Experiment with each mode to understand its strengths and weaknesses, adapting your approach based on the terrain and desired targets.

All Metal Mode

All Metal Mode on the Garrett ACE 250 is a non-discriminating search mode, meaning it detects all types of metal – iron, nickel, aluminum, gold, silver, and more. This mode provides the greatest detection depth, making it ideal for locating deeply buried targets. However, it also means you’ll encounter more unwanted signals from trash like iron nails and bottle caps.

Experienced users often utilize All Metal Mode for locating larger, deeper targets before switching to a discriminated mode for pinpointing. Careful attention to audio signals and target ID numbers is crucial in this mode to differentiate valuable finds from junk.

Jewelry Mode

Jewelry Mode on the Garrett ACE 250 is pre-programmed to enhance the detection of valuable metallic jewelry items like rings, necklaces, and earrings. This mode filters out most iron and some other unwanted targets, focusing the detector’s sensitivity on the conductive properties common in precious metals;

While effective for jewelry hunting, remember that Jewelry Mode may reduce detection depth compared to All Metal Mode; It’s best used in areas with moderate trash levels. Pay close attention to the target ID numbers and audio tones, as some gold items may register with lower ID values.

Custom Mode

Custom Mode allows experienced users to personalize their Garrett ACE 250’s settings for specific hunting conditions. This mode provides full control over discrimination patterns, frequency adjustment, and sensitivity levels. You can tailor the detector to minimize interference in heavily trash-filled areas or maximize depth in clean locations.

Experiment with different discrimination segments to reject unwanted targets while retaining sensitivity to desired items. Remember to save your preferred settings for quick recall. Custom Mode requires a good understanding of target ID numbers and audio signals to achieve optimal results. Careful adjustment is key to successful detecting.

Advanced Settings and Customization

Advanced Settings unlock the full potential of your Garrett ACE 250. Beyond basic modes, you can fine-tune the detector’s performance. Frequency Adjustment allows subtle shifts to minimize interference from electromagnetic sources, improving target separation. Explore Discrimination Patterns to selectively reject unwanted metals – iron, foil, or pull-tabs – while retaining sensitivity to valuable finds.

Customization extends to adjusting sensitivity levels for deeper detection or reduced noise. Experiment with these settings to optimize performance for different soil conditions and target types. Remember to document your preferred configurations for consistent results in familiar hunting locations.

Frequency Adjustment

Frequency Adjustment on the Garrett ACE 250 is a subtle but powerful tool for optimizing performance. While not a primary setting for beginners, it allows you to slightly shift the detector’s operating frequency. This can be crucial in areas with significant electromagnetic interference (EMI) from power lines, cell towers, or other metal detectors.

Small adjustments can reduce noise and improve target identification. Experiment with minor frequency shifts to find a “sweet spot” where unwanted signals diminish and desired targets become clearer. Remember to make small changes and test thoroughly, as excessive adjustment can negatively impact detection depth.

Discrimination Patterns

Discrimination Patterns on the Garrett ACE 250 allow you to selectively filter out unwanted metallic targets. The ACE 250 offers pre-set discrimination patterns, each designed for specific hunting scenarios. These patterns determine which metal types the detector will ignore, based on their conductive properties.

You can choose from patterns optimized for jewelry, coins, relics, or custom settings. Understanding these patterns is key to efficient treasure hunting. Experiment with different settings to minimize digging up trash like iron and aluminum while maximizing recovery of valuable finds. Careful adjustment of discrimination significantly improves your detecting experience.

Troubleshooting Common Issues

Troubleshooting the Garrett ACE 250 is often straightforward. False signals and interference can occur due to electrical sources or mineralized ground; try adjusting sensitivity or ground balance. Low battery issues are easily resolved by replacing the batteries with fresh ones – always use quality alkaline batteries for optimal performance.

If the detector isn’t responding, double-check all connections and ensure the coil is properly attached. Persistent issues might require resetting the detector to factory defaults; Refer to the full manual for detailed solutions and diagrams. Remember consistent performance relies on proper maintenance and care.

False Signals and Interference

False signals with the Garrett ACE 250 are common, often stemming from interference sources like power lines, cell towers, or even other metal detectors nearby. Mineralized ground can also mimic targets, creating unwanted signals. To minimize these, reduce sensitivity or adjust the discrimination settings to filter out unwanted metals.

Experiment with ground balance to compensate for soil conditions. Identifying the source of interference is key; moving to a different location can sometimes resolve the issue. Remember, consistent false readings suggest a potential problem requiring further investigation or a review of your settings.

Low Battery Issues

Low battery performance on the Garrett ACE 250 can manifest as erratic behavior, reduced sensitivity, or an inability to power on. Always use fresh, high-quality AA batteries – rechargeable batteries may not provide sufficient voltage. A flashing low battery icon on the display panel indicates imminent shutdown.

Replace batteries promptly to avoid losing detected targets or settings. If the detector powers on briefly then shuts off, batteries are likely the culprit. Consider carrying spare batteries during extended hunts. Ensure the battery compartment is clean and free of corrosion for optimal contact.

Maintenance and Care

Regular maintenance extends the life of your Garrett ACE 250. After each use, wipe down the detector with a damp cloth to remove dirt and debris, especially after saltwater exposure. Avoid abrasive cleaners that could damage the housing. Inspect the coil for damage and ensure the coil cable connection is secure.

Store the detector in a dry, cool place, away from direct sunlight and extreme temperatures. Remove batteries for long-term storage to prevent corrosion. Periodically check and tighten all screws and connections. Proper care ensures reliable performance for years of treasure hunting adventures.

Cleaning the Detector

Maintaining cleanliness is crucial for your Garrett ACE 250’s longevity. After each use, particularly in sandy or wet conditions, thoroughly clean the detector. Use a damp cloth with mild soap and water to wipe down the control box, armrest, and shaft. Avoid submerging the control box in water.

Pay special attention to the coil, removing any accumulated dirt or debris. Inspect the battery compartment for any signs of corrosion and clean if necessary. Ensure all components are completely dry before storing the detector. Regular cleaning prevents damage and ensures optimal performance during your detecting adventures.

Coil Protection and Storage

Protecting your coil is vital, as it’s the most vulnerable part of the ACE 250. When traversing rough terrain, avoid striking the coil against rocks or other hard objects. Consider using a coil cover to shield it from abrasions and impacts during use.

For storage, disconnect the coil from the shaft to prevent strain on the cable. Clean the coil thoroughly before storing it, removing any dirt or sand. Store the detector in a dry, cool place, away from direct sunlight and extreme temperatures. Proper coil care and storage will significantly extend the life of your Garrett ACE 250.

Safety Precautions

Always obtain permission before detecting on private property, and be aware of local laws and regulations regarding metal detecting. Fill in all holes you dig to avoid hazards to others. Be mindful of your surroundings and watch for potential dangers like traffic, uneven terrain, and wildlife.

Never operate the detector near power lines or during electrical storms. Avoid detecting in areas with underground utilities. When using headphones, keep the volume at a safe level to prevent hearing damage. Respect historical sites and report any significant finds to the appropriate authorities. Prioritize safety during every detecting session.

Legal Considerations and Responsible Detecting

Understanding and adhering to local laws is crucial. Always secure permission from landowners before detecting on private property. Be aware of regulations concerning archaeological sites and protected areas; disturbing these can lead to legal penalties. Practice responsible digging – fill all holes completely to prevent injury to people and animals.

Report significant finds to local authorities or archaeological societies. Respect the environment and avoid damaging vegetation or wildlife habitats. Follow the principle of “leave no trace.” Responsible detecting preserves history and ensures continued access to this enjoyable hobby for everyone. Ethical conduct is paramount.

Warranty Information

Garrett Metal Detectors provides a limited warranty on the ACE 250. This warranty typically covers defects in materials and workmanship for a period of one year from the date of original purchase. Proof of purchase is required for all warranty claims. The warranty does not cover damage caused by misuse, modification, accident, or normal wear and tear.

To initiate a warranty claim, contact Garrett customer support or an authorized Garrett dealer. Shipping costs to and from the repair facility are the responsibility of the owner. Garrett will, at its option, repair or replace the defective product. This warranty gives you specific legal rights, and you may have other rights which vary by location.
